Doctor Blades for Gravure & Flexo Presses — SC Series
Dekeer SC-series carbon steel doctor blades are made for high-end gravure and flexo presses. Multi-stage micro-grinding and dedicated heat-treatment lines give each blade extreme straightness, flatness and a flawless bevel — so print shops see fewer streaks, drag marks and ghosting, and color stays stable across long runs.
Key Performance Advantages of Our Printing Blades
Longer Press Runs Premium European carbon steel strip endures continuous speeds up to 200 m/min, so blade changes interrupt the press far less often. | Clean Ink Metering A precision-finished edge keeps stable micro-contact on ceramic anilox rollers for exact metering and consistent ink film thickness. |
Resists Aggressive Solvents Optimized steel microstructure fights wear and corrosion from aggressive solvent inks, varnishes and industrial coatings. | Wholesale OEM Service Custom thicknesses, slit widths and lamella edge profiles to match any blade clamp design worldwide — straight from the factory. |
Material Properties & Technical Parameters
| Structural Property | Engineering Value Range |
| Raw Material | High-carbon precision steel strip |
| Slit Width | 10-60 mm |
| Width Tolerance | ±0.10 mm |
| Thickness Options | 0.152 mm / 0.203 mm (custom runs available) |
| Thickness Tolerance | ±0.005 mm |
| Hardness Rating | 580 – 600 HV |
| Ultimate Tensile Strength | 1850 – 2000 MPa |
| Max Straightness Deviation | ≤0.5 mm / 3000 mm |
Standard Roll Dimension Guide
| Blade Width (mm) | Blade Thickness (mm) | Standard Roll Length (m) |
| 10 / 30 / 35 | 0.15mm / 0.20mm | 100m Coils |
| 40 / 50 / 60 | 0.15mm / 0.20mm | 100m Coils |
